HHH (3 Humbuckers) — 3 Volume, 2 Tone, 5-Way Switch
Click the image to download the diagram, or use the link below.
GKW kits that use this wiring
- 3-pickup double cutaway: SG3-C-1, SG3-RMEC-2299, SG3-RMEG-1
Tips
- Each humbucker has its own volume control. The 5-way switch gives you: bridge, bridge+middle, middle, middle+neck, neck. Set unused pickup volumes to zero for cleaner switching.
- Wire colors may vary between kit batches — match by position, not color.
- Need soldering help? See our Electric Guitar Wiring guide for basics.
